Light Block LED 24V White Flashing
Telemecanique

Light Block LED 24V White Flashing

Ideal part number TELZBV18B1 Manufacturer number ZBV18B1 Barcode 3389110861136
Request a quote for this product

Enter details to request a quote
Need help choosing the right product? Talk to your local team

Product details

Light block, Harmony XB4, Harmony XB5, flashing, for head 22mm, universal LED, screw clamp terminals, 24V

This Harmony ZB, white flashing light block operates with a universal LED. It is supplied with 24V AC/DC and uses screw-clamp terminals. It is compatible with Harmony XB4 and XB5. This light block allows fast and easy replacement and configuration of your signaling units. It is easily installed and replaced on compatible illuminated push-button or selector switch units via clip together assembly and connected with simple screw-clamp connections. It enables visual distinction of signaling units via illumination by universal LED. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product. Vibration resistant screw clamp connection terminals ensure high vibration resistance making product suitable installation on high impact machine.

Technical specifications

Lamp holder
Other
Transformer integrated
no
With integrated voltage decreasing resistor
no
With integrated diode
yes
Colour light source
White
Lamp type
LED
Type of fastening
Front fastening
With light source
yes
Connection type auxiliary circuit
Screw connection
Rated voltage Ue at AC 50 Hz
24 V
Rated voltage Ue at AC 60 Hz
24 V
Rated voltage Ue at DC
24 V
Voltage type for actuating
AC/DC
